Gigabyte B850 FORCE WiFi6E AMD Motherboard
GIGABYTE B850 FORCE WiFi6E (AMD AM5) – ATX Motherboard
GIGABYTE's advanced ATX motherboard is designed for next-generation gamers and professional users. Designed to support AMD Ryzen™ 7000 to 9000 processors via the AM5 socket, it offers a fully future-proof experience with DDR5 support, PCIe 5.0, and advanced wireless connectivity.
Featured Specifications:
Socket: AMD AM5 – Fully supports Ryzen 7000/8000/9000 processors
Chipset: AMD B850 – The current replacement for the B650 in the AMD lineup
Power Management (VRM): 8+2+2 digital power phase design to ensure voltage stability and reliable operation, even with the most efficient processors
Memory: Four dual-channel DDR5 sockets, up to 256 GB, supporting frequencies up to 8200 MT/s with AMD EXPO and XMP support
PCIe/Storage Slots:
One PCIe 5.0 x16 slot (with EZ-Latch Plus design for easy installation)
Three M.2 slots: (One PCIe 5.0 x4 Two PCIe 4.0 x4)
Four SATA 6Gb/s ports + advanced RAID support (0, 1, 5, 10)
Cooling and Protection: VRM with advanced cooling (Thermal Armor Advanced) and M.2 thermal pads to protect the SSD and maintain performance
Network and Connectivity:
Wi-Fi 6E (802.11ax) with high-gain antenna (Wi-Fi EZ-Plug) and Bluetooth 5.3
Built-in 2.5GbE LAN
Rear Ports:
HDMI 2.1 (4K@60Hz) and DisplayPort 1.4 (4K@144Hz) for integrated graphics support
USB: USB-C USB-A (3.2 Gen1/Gen2) and additional USB 2.0 ports
Unique Software and Features:
X3D Turbo Mode for one-click Ryzen X3D performance boosts via BIOS and GIGABYTE Control Center
Complementary features such as EZ-Latch Plus for screwless installation, Q-Flash Plus, and an advanced BIOS interface with Smart Fan 6
RGB Fusion support and lighting control
Future Compatibility:
With its feature set and support for future processors, this motherboard is a solid investment option for building a sustainable and flexible AM5 system.
Payment Methods Available
| Brand: GIGABYTE |
| Motherboard Model: B850M FORCE WIFI6E AMD |
| Motherboard Form Factor: M-ATX |
| Motherboard Chipset: AMD B850 |
| Socket Type: AM5 |
| WIFI & Bluetooth: Wi-Fi 6E/BLUETOOTH 5.3 |
| Ram Type: DDR5 |
| RAM Pack/Socket: 2 |
| PCIe Express: 5.0 |
| Storage Interface: NVMe PCIe/SATA |
| M.2 Slot: 3 |
| SATA Slot: 4 |
| CPU Power PIN: 8 |
| RGB Fan Support: ARGB Sync |
| Watt: 55 |
| Case Form Factor: E-ATX-ATX-MATX |
Barcode:
B850M-FORCE-WF6E
